Dry Barrel Fire Hydrant
The BT 5221 Dry Barrel Fire Hydrant is designed to provide a reliable water supply for firefighting applications in areas exposed to freezing conditions. Its dry barrel design keeps water below ground level when not in use, preventing damage caused by frost. Manufactured in accordance with AWWA C502 standards, the hydrant offers excellent flow performance, durable construction, and dependable operation. It is suitable for municipal, industrial, commercial, and infrastructure fire protection systems, with multiple nozzle configurations available to meet various installation requirements.
-
UL 246 Listed
-
Max Working Pressure 17.2 Bar ( 250 psi)
-
Meets or Exceeds the Requirements of AWWA C502 Standard.
-
NFPA 1963 Standard Nozzle Threads.
-
Traffic Feature with Duplex Stainless Steel Safety Stem Coupling.
-
Excellent Flow Characteristics.
-
Dry Top Design with O-ring Sealed Oil Reservoir.
-
Dual Auto-frost Bronze Drain Valves as Standard.
-
Fusion Bonded Epoxy Coating
